| Qubed POS600

The POS600 is an all-in-one fanless POS system.

Robust unit with touch screen and industrial motherboard, and aluminum housing.

Well suited for retail and hospitality industries with excellent performance.

1 5

| Key Features

High performance & low power consumption

Projective capacitive touch screen

Vesa wall mount capability

Splash-proof, dust-proof

Modular architecture

Aluminum housing for heat disbursement

Unit is fan-less


| Specifications (Windows)

  • CPU

    Elkhart J6412 FANLESS

    (Optional I3)

    Memory RAM

    DDR4 8GB

    HDD/SDD

    128GB mSATA

    (256GB mSATA upgrade available)

  • OS

    Windows 10/11 or Linux

    Touch Panel

    PCAP touch with multi-touch support

    WiFi

    Optional, IEEE 802.11b/g/n

    Power Adapter
    DC 12V/4A

    Ethernet

    1*10/100M

    1*10/1000M (I3)

  • Bluetooth

    Optional, BT4.0

    Dimensions (mm)

    343*223*357

    Display

    Main display:

    15.6" TFT 1920*1080
    2nd display (optional):
    9.7'' TFT 1920*768,

    15.6" TFT 1920*1080

    2x20 LCD customer display

  • I/O Ports

    7xUSB, 4xRS232, 1xRJ45, 1xCash drawer, 1xHDMI, 1x12V DC out

    Optional

    MSR, 2D Barcode Scanner, or Biometric Fingerprint Reader

Download POS600 Brochure

Please contact us if you would like to receive more information.
