| Qubed POS80
Fashionable design
80mm Thermal Printer with auto-cutter
Well suited to many environments
Unique design all-in-one touch POS
Flexible configurations with multi-optional peripherals
| Key Features
Aesthetically Pleasing
Splash-proof and Dust-proof
Modular Architecture
Custom Design Options
Options with or without Printer
Small Footprint & Lightweight
Optional 3D Camera for Facial Recognition
| Specifications (Windows)
The unit is available in both Windows and Android OS options
-
CPU
Baytrail J1900 (Current)
i3 and i5 options are available
Memory RAM
DDRIII 8GB
HDD/SDD
256GB mSATA SSD
Display
Main display:
15.6" TFT 1920*1080
2nd display (optional):
15.6'' TFT 1920*1080,7'' TFT 1024*600
-
OS
Windows 7/10,/11 or Linux
Touch Panel
PCAP touch with multi-touch support
WiFi
Optional, IEEE 802.11b/g/n
Power Adapter
DC 24V/2.75A (w/ printer)
DC 12V/4A (w/o printer)Ethernet
1*10/100M
-
Printer
80mm thermal printer
w/Auto Cutter
(optional w/o printer)
Bluetooth
Optional, BT4.0
Dimensions (mm)
378*353*24.mm
350*360*240 mm
(w/ printer)
-
I/O Ports
6*USB,
2*RS232, 1*Cash Drawer, 1*Lan, 1*24V DC In (w/ printer)Speaker
1*3W speaker
Optional
MSR, 3D Camera, 2D Barcode Scanner, or Biometric Fingerprint Reader
| Specifications (Android)
The unit is available in both Windows and Android OS options
-
CPU
RK3288 QuadCore 1.8GHz
Memory RAM
4GB
HDD/SDD
32GB
Display
Main display:
15.6" TFT 1920*1080
2nd display (optional):
15.6'' TFT 1920*1080,7'' TFT 1024*600
-
OS
Android 7.1
Touch Panel
PCAP touch with multi-touch support
WiFi
IEEE 802.11b/g/n
Power Adapter
DC 24V/2.75A (w/ printer)
Ethernet
1*10/100M
-
Printer
80mm thermal printer
w/Auto Cutter
(optional w/o printer)
Bluetooth
BT4.0
Dimensions (mm)
378*353*242/ 350*360*240 mm (w/ printer)
-
I/O Ports
6*USB, 2*RS232, 1*Cash Drawer, 1*RJ45, 1*USB OTG, 1*24V DC In (w/ printer)
Speaker
1*3W speaker
Optional
MSR, 3D Camera, 2D Barcode Scanner
Download POS80 Brochure
Please contact us if you would like to receive more information.
